Range of reproduced frequencies:
70Hz - 200Hz (-3dB)*
50Hz - 400Hz (-10dB)*
* measurements made in halfspace conditions
using dedicated filters in the VMBS18215 preset.
Recommended frequency range: Specified for the configuration in the VMBS 18215 preset
Recommended RMS amplifier power: VMS 1815 system amplifier
Nominal speaker power: 400W AES / 600 Continuous / 1200 Program
SPL efficiency (1W/1m): 99dB
Maximum SPL (peakCF4 12dB): 135dB**
Speaker: 15" woofer, 3" voice coil, Xmax 8mm, neodymium magnet
Impedance: 8 Ω
Connectors: 2x Neutrik NL4MP
Dimensions (H x W x D): 600mm x 470mm x 460mm
Weight: 19 kg
** max SPL (peak) at 1m in halfspace conditions, using 12dB Crest factor pink noise via dedicated DSP with product-specific setting.
